(Sugoi! Arcana Heart 2)
An updated version of Arcana Heart 2. It brought some balance and design changes. The main differences are:
- Illustrations of the character images, and redesigned Hirotaka Kaya to be painted red.
- One additional character.
- One additional stage.
- One new color set for the characters, selected by pressing the START button when selecting the character.
- Game balancing.
- Additional training mode.
- Some bug fixes.
Examu eX-BOARD hardware
CPU â Fanless Via C7 NanoBGA2
Chipset â Via CN700, VT8237R Plus
Memory â 1GB DDR2 SDRAM (with VRAM sharing)
Video â Integrated S3 UniChrome Pro AGP graphics with MPEG-2 decoding
acceleration
Audio â VIA VT1618Cidec 192KHz/32bit 8 channel ACâ97
Network â RJ-45 10/100Mbps ethernet
Video I/O â JAMMA output; D-Sub 15-pin X 2/composite terminal/terminal
S-Video (able to connect simultaneously).
Sound I/O â JAMMA output/ left/right voice output terminal X 2
Input â Operators are able to add buttons with JAMMA input
USB â Two USB 2.0 ports
Power â JAMMA supply 12V 5A; or special power supply adaptor with
AC100-240V 50/60Hz 1.7A
Size â W317.8mm x D250mm x H104.2mm
Weight â 4kg
Operating System â Microsoft Windows XP Embedded
Flash Disk â 512MB/1GB/2GB
Sugoi Arcana Heart 2 was released on October 30, 2008.
Sony PS2 (Oct. 30, 2008)
